It's hot in summer, especially for the Shandong air compressor that keeps working in high temperature. How to check and deal with the shutdown of Shandong air compressor at high temperature, how to cause it, and how to deal with it. Below, Qingyue energy saving will solve your problems.

一、檢查空壓機的冷卻器，如果是風冷方式的冷卻器，就檢查灰塵是否過多了，過多容易導致通風不良，使空壓機設備達不到足夠的散熱，容易出現高溫的情況；水冷的冷卻器就檢查有沒有過多水垢產生了堵塞，帶不走油點溫度，達不到散熱效果。

1、 Check the cooler of the air compressor. If it is an air-cooled cooler, check whether there is too much dust. Too much dust can easily lead to poor ventilation, so that the air compressor equipment can not achieve sufficient heat dissipation and is prone to high temperature; The water-cooled cooler will check whether there is too much scale and blockage, which can not take away the oil point temperature and can not achieve the heat dissipation effect.

二、檢查空壓機機油、油位是否已經少于機油窺視鏡低限度。機油過少的情況下，空壓機在整個運行過程中是得不到足夠的冷卻和潤滑作用的。

2、 Check whether the oil and oil level of the air compressor have been less than the low limit of the oil sight glass. Under the condition of too little oil, the air compressor can not get enough cooling and lubrication during the whole operation process.

三、要做好溫控閥的檢查，溫控閥它好比一個四通閥，在溫度低的時候機油循環是從油分離器直接通到主機頭里潤滑散熱，當機油循環中溫度一般達到80-88度左右的時候溫控閥會漸漸打開讓油分離器的機油通過冷卻器冷卻后再送到主機里達到冷卻循環的作用。  四、要檢查斷油閥和油過濾，油過濾堵塞會導致主機頭進油量過少，一般油過濾是周期性的必 須更換。而斷油閥沒有完全打開也會導致進油量過少都會讓主機頭逐漸升溫，直到報警停機為止。

3、 Check the temperature control valve. The temperature control valve is like a four-way valve. When the temperature is low, the oil circulation is directly connected from the oil separator to the main engine head for lubrication and heat dissipation. When the temperature in the oil circulation generally reaches about 80-88 degrees, the temperature control valve will gradually open to allow the oil of the oil separator to be cooled through the cooler and then sent to the main engine to achieve the function of cooling circulation. 4、 Check the oil cut-off valve and oil filter. The blockage of oil filter will lead to too little oil inlet into the main engine head. Generally, the oil filter is periodic and must be replaced. If the oil cut-off valve is not fully opened, it will also lead to too little oil inlet, which will gradually raise the temperature of the main engine head until the alarm stops.

五、要檢查溫度傳感器和溫度開關，這是很重要的一個檢查，溫度傳感器，是一個熱電阻，起到一個探測信號的作用，把信號傳到電腦主控器里邊。如果傳感器故障，就會出現探測的溫度不準確，還有傳感器的線接觸不好等都會引起主控警聲停機的。

5、 It is very important to check the temperature sensor and temperature switch. The temperature sensor is a thermal resistor, which plays the role of detecting the signal and transmits the signal to the computer main controller. If the sensor fails, the detected temperature will be inaccurate, and the line contact of the sensor is poor, which will cause the main control alarm to stop.

當然這五個檢查是在出現空壓機高溫時候比較容易出現的情況，也不排除其他可能，如是否機頭的異響，某個部件損壞，空壓機起到自身的保護作用產生的預警，所以停機了。

Of course, these five inspections are more likely to occur when the air compressor is at high temperature, and other possibilities are not ruled out, such as whether the abnormal noise of the machine head, the damage of a component, and the air compressor plays its own protective role, so it is shut down.
