空壓機配件高溫故障怎么辦

相對于活塞式空壓機，空壓機的配件較多：傳感器、溫控閥、過濾器、主控器等等，這也造就了螺桿式空壓機相對活塞機結構較復雜，后期的維護保養也就顯得重要一些。

Compared with the piston air compressor, the air compressor has more accessories: sensor, temperature control valve, filter, main controller, etc., which also makes the screw type air compressor relatively complex compared with the piston machine, and the later maintenance is also important.

當然面對高溫環境，配件的運行狀態也就需要注意：空壓機配件正常運行的溫度在75℃-95℃，當高于這個溫度上限時，屬于高溫。引起高溫的原因有許多，分析并判斷空壓機高溫的起因，才是解決高溫的前提基礎。

Of course, in the face of high temperature environment, the operating state of accessories also needs attention: the normal operation temperature of air compressor accessories is 75 ℃ - 95 ℃. When it is higher than the upper temperature limit, it belongs to high temperature. There are many causes of high temperature. Analyzing and judging the cause of high temperature of air compressor is the premise of solving high temperature.

一：主控器故障。出現亂報警的情況。如果是因為這個原因才出現空壓機面板上顯示高溫。解決方案：更換新的主控器。

1： Master controller failure. There is a random alarm situation. If it is because of this reason that the air compressor panel shows high temperature. Solution: replace the main controller with a new one.

二：油過濾器堵塞。油過濾器的作用是將潤滑油中的雜質過濾，保護空壓機的主機。如果長時間不更換，或是使用的環境比較惡劣，導致油過濾器堵塞，壓縮機內部的油路流量小，主機不能及時的獲得足夠量的潤滑油冷卻，會出現高溫現象。解決方案：更換油過濾器，或是做一次油路保養。

2： The oil filter is blocked. The function of oil filter is to filter the impurities in lubricating oil and protect the host of air compressor. If the oil filter is not replaced for a long time, or the use environment is relatively bad, resulting in the blockage of the oil filter, the internal oil flow of the compressor is small, and the main engine can not get enough lubricating oil cooling in time, the phenomenon of high temperature will occur. Solution: replace the oil filter, or do a maintenance of the oil circuit.

三：缺少潤滑油?？諌簷C的潤滑油不僅有潤滑、密封作用，它主要的是還可以冷卻機組，因而也稱作“冷卻液”，當機器缺少冷卻液時，空氣壓縮機產生的熱得不到冷卻，則溫度就會越升越高，這也是引起空壓機高溫的主要因素之一。解決方案：添加空壓機油，如果是潤滑油油品變質導致的高溫，則更換。

3： Lack of lubricating oil. The lubricating oil of air compressor not only has the function of lubrication and sealing, but also can cool the unit, so it is also called "coolant". When the machine is short of coolant, the heat generated by the air compressor can not be cooled, and the temperature will rise higher and higher, which is one of the main factors causing high temperature of air compressor. Solution: add air compressor oil, if it is high temperature caused by deterioration of lubricating oil, replace it.

四；溫控閥故障。溫控閥的作用是控制空壓機主機的噴油溫度；它利用溫控元件根據油溫控制該元件閥芯的開啟度，從而控制通過油冷卻器的油量，讓冷，熱油混合后到主機去，從而控制了噴油及排氣溫度！解決方案：更換溫控閥芯。

4、 Temperature control valve failure. The function of the temperature control valve is to control the injection temperature of the air compressor main engine; it uses the temperature control element to control the opening degree of the valve core of the element according to the oil temperature, so as to control the amount of oil through the oil cooler, so as to mix the cold and hot oil to the main engine, so as to control the oil injection and exhaust temperature! Solution: replace the temperature control valve core.
